HashiCorp Vault for MFA-Gated SSH Session TTLs (MA.L2-3.7.5)

A hashicorp vault mfa ssh session ttl design can satisfy MA.L2-3.7.5 by requiring MFA before Vault issues a short-lived SSH certificate, limiting the certificate to a maintenance account, and using a server-side session timer to close the SSH shell even if the technician forgets to disconnect. Vault controls identity verification, certificate issuance, and credential lifetime; the SSH server enforces the maximum live-session duration, while the ISSO or FSO retains responsibility for approving maintenance, reviewing evidence, and confirming the external connection is closed when work is complete.

What does hashicorp vault mfa ssh session ttl automation handle, and what remains manual?

NIST SP 800-171 Rev. 2 practice MA.L2-3.7.5 requires two distinct outcomes: MFA must be used to establish nonlocal maintenance sessions over external networks, and those sessions must be terminated when the maintenance activity is complete. A Vault-issued SSH certificate with a 20-minute maximum lifetime is useful, but certificate expiration alone does not reliably terminate an SSH session already in progress. The implementation needs both a short certificate TTL and a server-side timeout.

For a small contractor, keep the boundary clear: a CI runner or service account must never receive the human remote-maintenance signing policy. A scheduled job can validate configuration drift, but it cannot perform MFA on behalf of a technician.

How can you automate MFA-gated SSH certificate issuance?

The following Bash workflow assumes Vault Enterprise MFA enforcement, an existing OIDC authentication mount, and an identity provider configured to require MFA for the remote-maintenance group. Vault MFA enforcement adds a second factor at the Vault login layer; the OIDC role should also require an MFA-related claim, such as an amr value containing mfa, where the identity provider supports that claim.

The first script creates a Duo MFA method, applies MFA enforcement to the OIDC mount, enables an SSH certificate authority, and creates a narrowly scoped signing role. Store the Duo integration values in an approved secret store or protected deployment environment; do not place them in a repository or a Terraform variable file.

#!/usr/bin/env bash
set -euo pipefail

: "${VAULT_ADDR:?Set VAULT_ADDR}"
: "${VAULT_TOKEN:?Use an approved Vault administrator token}"
: "${DUO_IKEY:?Load from protected automation secrets}"
: "${DUO_SKEY:?Load from protected automation secrets}"
: "${DUO_HOST:?Example: api-xxxxxxxx.duosecurity.com}"

export VAULT_ADDR VAULT_TOKEN

OIDC_ACCESSOR="$(vault auth list -format=json | jq -r '.["oidc/"].accessor')"

MFA_ID="$(vault write -format=json sys/mfa/method/duo \
  name=remote-maint-duo \
  integration_key="$DUO_IKEY" \
  secret_key="$DUO_SKEY" \
  api_hostname="$DUO_HOST" | jq -r '.data.method_id')"

vault write identity/mfa/login-enforcement/remote-maintenance \
  mfa_method_ids="$MFA_ID" \
  auth_method_accessors="$OIDC_ACCESSOR"

vault secrets list -format=json | jq -e 'has("ssh-client-signer/")' \
  || vault secrets enable -path=ssh-client-signer ssh

vault write ssh-client-signer/config/ca generate_signing_key=true

vault write ssh-client-signer/roles/remote-maint \
  key_type=ca \
  allow_user_certificates=true \
  allowed_users=maint-remote \
  default_user=maint-remote \
  ttl=20m \
  max_ttl=20m \
  allowed_extensions=permit-pty \
  default_extensions='{"permit-pty":""}'

cat > remote-maint-policy.hcl <<'EOF'
path "ssh-client-signer/sign/remote-maint" {
  capabilities = ["create", "update"]
}
EOF

vault policy write remote-maint remote-maint-policy.hcl

Attach the remote-maint policy only to the OIDC role or identity group used for approved maintenance staff. Do not grant that group access to arbitrary Vault paths, SSH host keys, or broader privileged-administration policies. The policy is intentionally limited to signing a certificate through one role.

How should the SSH server enforce the live-session limit?

On every in-scope maintenance target, install the Vault SSH CA public key and restrict the maintenance account. This example fits a 62-person electronics and PCB manufacturer where two outside field-service technicians maintain a Linux test-data server and a production programming appliance during approved evening windows. The company’s normal engineering accounts cannot use this maintenance account.

#!/usr/bin/env bash
set -euo pipefail

vault read -field=public_key ssh-client-signer/public_key \
  | sudo tee /etc/ssh/trusted-user-ca-keys.pem > /dev/null

sudo install -m 0755 /dev/stdin /usr/local/sbin/maintenance-shell <<'EOF'
#!/usr/bin/env bash
set -euo pipefail
limit_seconds="${1:?Missing session limit}"
logger -p authpriv.notice "remote maintenance shell started for ${USER}"
exec /usr/bin/timeout --foreground --signal=TERM --kill-after=30s \
  "$limit_seconds" /bin/bash -l
EOF

sudo tee /etc/ssh/sshd_config.d/50-remote-maintenance.conf > /dev/null <<'EOF'
TrustedUserCAKeys /etc/ssh/trusted-user-ca-keys.pem
ClientAliveInterval 60
ClientAliveCountMax 2

Match User maint-remote
    PasswordAuthentication no
    PubkeyAuthentication yes
    AuthenticationMethods publickey
    PermitRootLogin no
    AllowTcpForwarding no
    X11Forwarding no
    PermitTunnel no
    ForceCommand /usr/local/sbin/maintenance-shell 1200
EOF

sudo sshd -t
sudo systemctl reload sshd

The 1,200-second forced shell matches the 20-minute certificate maximum. The certificate prevents new access after expiration; the forced command closes an established interactive shell at the same limit. If the technician completes work earlier, they must use exit, which is the operational termination event recorded in the maintenance ticket. Use a separate, purpose-built transfer method for files because a forced interactive shell will interfere with SCP and similar workflows.

What does the technician’s approved workflow look like?

#!/usr/bin/env bash
set -euo pipefail

KEY="$(mktemp -u "${TMPDIR:-/tmp}/maint-key.XXXXXX")"
CERT="${KEY}-cert.pub"
trap 'rm -f "$KEY" "$KEY.pub" "$CERT"' EXIT

ssh-keygen -q -t ed25519 -N "" -f "$KEY"

# Browser-based OIDC login must complete the approved MFA challenge.
vault login -method=oidc role=remote-maint

vault write -field=signed_key \
  ssh-client-signer/sign/remote-maint \
  public_key=@"$KEY.pub" \
  valid_principals=maint-remote \
  ttl=20m > "$CERT"

ssh -i "$KEY" \
  -o CertificateFile="$CERT" \
  -o IdentitiesOnly=yes \
  maint-remote@maintenance-gateway.example.mil

# Technician exits when maintenance is complete; the trap removes local keys.

How should this be integrated into CI/CD or scheduled jobs?

Use scheduled automation for configuration validation, not for human session creation. A GitHub Actions workflow running from a protected, self-hosted runner can authenticate to Vault using a dedicated GitHub JWT role with read-only access to the SSH role configuration. It should verify that the certificate ceiling remains 20 minutes and that each target still has the required SSH server directives.

name: Validate remote-maintenance controls

on:
  schedule:
    - cron: "17 3 * * 1-5"
  workflow_dispatch:

permissions:
  id-token: write
  contents: read

jobs:
  validate:
    runs-on: [self-hosted, management-subnet]
    steps:
      - uses: actions/checkout@v4
      - name: Authenticate with Vault using GitHub OIDC
        uses: hashicorp/vault-action@v3
        with:
          url: $
          method: jwt
          path: jwt
          role: github-compliance-read
      - name: Check certificate and SSH session limits
        run: |
          set -euo pipefail
          vault read -format=json ssh-client-signer/roles/remote-maint \
            | jq -e '.data.max_ttl == 1200 and .data.ttl == 1200'
          ssh maintenance-gateway.example.mil \
            'sudo sshd -T -C user=maint-remote,host=maintenance-gateway,addr=10.20.30.40' \
            | grep -Fx 'forcecommand /usr/local/sbin/maintenance-shell 1200'

Route a failed workflow to the compliance ticket queue. A failed validation does not prove an unauthorized session occurred, but it does establish that a control dependency needs immediate review before the next external maintenance window.

Which monitoring and alerting hooks provide MA.L2-3.7.5 evidence?

Forward Vault audit logs to the SIEM through an approved audit device, protect them from alteration, and retain the ticket number, technician identity, target system, certificate issuance event, SSH login event, and logout or timeout event as one reviewable record.

What failure modes should the ISSO plan for?

As the ISSO or FSO, schedule a tabletop test with the maintenance owner this month: prove MFA is challenged, prove the forced shell ends at the configured limit, and attach the resulting Vault, SSH, and firewall evidence to your MA.L2-3.7.5 assessment record.
